Where applications call for maximum conformity and deformation resistance, American Biltrite offers reinforced sheet rubber in several popular combinations of fabric and compounds. Custom compounding and fabrication of reinforced sheet products can be specified to match unique application requirements.
In this section, you will find C.I. Packing products as well as Diaphragm sheet rubber. Fabric reinforced rubber presents good dimensional stability under high compression loads. To compare the advantages and limitations of each polymer, see respective polymer sections.
Style | Duro | Grade | Tensile (PSI) | Ultimate elongation (%) | Temperature range | Finish | Color | |
---|---|---|---|---|---|---|---|---|
|
AB-2102 Styrene-Butadiene (SBR) |
60 | Industrial | 700 min. | 250 min. |
-20° to 180°F
-29° to 82°C |
Smooth | Black |
|
AB-3205 Neoprene-Polychloroprene (CR) |
70 | Industrial | 1400 min. | 250 min. |
-20° to 212°F
-29° to 100° |
Smooth | Black |
|
AB-3210 Neoprene-Polychloroprene (CR) |
70 | Industrial | 1400 min. | 250 min. |
-20° to 212°F
-29° to 100° |
Smooth | Black |
|
AB-3220 Neoprene-Polychloroprene (CR) |
65 | Commercial | 600 min. | 300 min. |
-20° to 190°F
-29° to 88°C |
Smooth | Black |
|
AB-3228 Neoprene-Polychloroprene (CR) |
65 | Commercial | 600 min. | 300 min. |
-20° to 190°F
-29° to 88°C |
Smooth | Black |
|
AB-3275 Neoprene-Polychloroprene (CR) |
70 | Industrial | 1200 min. | 250 min. |
-20° to 190°F
-29° to 88°C |
Smooth | Black |
|
AB-3560 Ethylene Propylene Diene (EPDM) |
60 | Industrial | 800 min. | 250 min. |
-40° to 250°F
-40° to 121° |
Smooth | Black |
|
AB-951 Neoprene-Polychloroprene (CR) |
65 | Industrial | 600 min. | 300 min. |
-20° to 190°F
-29° to 88°C |
Smooth | Black |
|
AB-984 Styrene-Butadiene (SBR) |
80 | Industrial | 500 min. | 100 min. |
-20° to 180°F
-29° to 82°C |
Smooth | Black |
|
IM-2100 Styrene-Butadiene (SBR) |
65 | Commercial | 500 nom. |
-20° à 180°F
-29° à 82°C |
Smooth | Black | |
|
IM-950 Neoprene-Polychloroprene (CR) |
65 | Commercial | 600 min. |
-20° to 190°F
-29° to 88°C |
Smooth | Black |
